Description
The HST (Lift & Slide) system is available in two depth options: 173 mm and 214 mm, with compatible glazing unit thicknesses ranging from 24 mm up to 32 mm. This timber system supports multiple opening configurations – up to 6 sashes, each capable of handling a maximum weight of 400 kg. Additionally, the system can be equipped with electric drives, operable via wall switch or remote control for added convenience.
Technical Data
| Frame thickness | 173 mm, 214 mm |
|---|---|
| Gasket | EPDM |
| Available glazing unit thickness | 24 mm – 32 mm |
| Standard glazing | 4/16Ar/4 [Rw=32dB, Lt=82%, g=65%] |
| Profile structure | Laminated glued squared timber |
| Standard handle | System handle |
| Warranty | 2 years on the structure |
| Certifications | CE, ITB, ITT, FSC |
| Turnaround | 9 – 14 weeks |
